Video:

• Input: 64 Channel via Standard network connection (1 x RJ-45 Network Port)
• Output: VGA (HDMI Mirror): 1280x1024, 1920x1080 (1080P)
• HDMI1: 1280x1024, 1920x1080 (1080P)
• HDMI2: 1280x1024, 1920x1080 (1080P), 3840x2160 (4K)

Bandwidth:

• Incoming: 320Mbps
• Outgoing: 320Mbps

Decoding Support:

• H.265
• H.264

Recording:

• Real-Time 64CH 5MP
• FPS: 1600 (PAL) / 1920 (NTSC)
• Resolution: 2592x1944

Playback:

• 16 Channels Simultaneously

Audio:

• Input: 1 Channel on device (RCA) + IP Camera inputs
• Output: 1 Channel on device (RCA)
• 2 Way audio

Alarm:

• Input: 8 Dry Contacts + IP Camera inputs
• Output: 4 Dry Contacts + IP Camera outputs

Storage:

• 8 x SATA (Up to 6TB Each)

USB Port:

• 2 x USB2.0
• 1 x USB3.0

Network:

2xRJ-45: 1000Mbps Each
