Video:

• Input:  2 x RJ-45 Network (1000Mbps) Support
• Output: HDMI x 2 + VGA, Dual display mode
• HDMI1:  4K, 1920x1080 (1080P), 1280x1024
• HDMI2 / VGA:  1920x1080 (1080P), 1280x1024

Bandwidth:

• Incoming: 384Mbps
• Outgoing: 384Mbps

Decoding Support:

• H.265, H.264

Recording:

• Resolution: 8MP & lower
• Real-Time 128CH 8MP, 5MP, 4MP, 3MP, 1080P, 960P, 720P, D1
• FPS:  3200(PAL) / 3840 (NTSC)

Playback:

• 16 Channels Simultaneously (locally), 9Channels (Remotlly).

Audio: Two way audio

• Input: 1 Channel + Depends on  Camera inputs
• Output: 1 Channel on device (RCA)

Alarm:

• Input: 8 Physical Alarm channels + IP Camera inputs
• Output: 4 Physical Alarm channels + IP Camera outputs only

Storage:

• 16 x SATA Hot swap (Up to 8TB Each)
• USB Port: total 3
• 1 x USB3.0, 2 x USB2.0
• E-Sata x 1

Network: 2 x RJ-45

• 2 x 1000Mbps
