SH-4050A5N-5L(MM)
Video:
Input: 4CH Standard BNC + 2CH IP (Over Network)
Output: HDMI(1920x1080), VGA (1280x1024, 1024x768), CVBS(Spot)
Recording:
IP: 5MP and lower: 30/25FPS Per Channel
AHD: 5MP Lite: Up to 10FPS Per Channel, 4MP Lite / 2MP: Up to 12/15FPS Per Channel, 2MP Lite / 1MP: Up to 25/30FPS Per Channel
TVI: 5MP Lite: Up to 10FPS Per Channel, 4MP Lite / 2MP: Up to 12/15FPS Per Channel, 2MP Lite / 1MP: Up to 25/30FPS Per Channel
CVI: 4MP Lite / 2MP: Up to 15/12FPS Per Channel, 2MP Lite / 1MP: Up to 25/30FPS Per Channel
CVBS: 960H: Up to 30/25FPS Per Channel
Playback:
4 Channel Simultaneously (Local)
4 Channel Simultaneously (Remote)
Analytics:
For IP Channels: Line Crossing (With Direction Choice), Sterile Area, Item Monitoring, Camera Tampering, Smart Search
For HD Analog Channels: Line Crossing (No Direction Choice), Sterile Area, Smart Search
Bandwidth:
Incoming: 16Mbps
Outgoing: 40Mbps
Audio:
Input: 1 Channel (RCA) + IP Cameras inputs
Output: 1 Channel (RCA) + IP Cameras outputs
2 Way audio
Storage:
1 x SATA (Up to 6TB)
USB Port:
2 x USB2.0
Network:
RJ-45: 100Mbps
Alarm:
IP Cameras inputs
IP Cameras outputs
PTZ / Keyboard:
Connection: RS-485 / CoC / IP-Over Network
Supported Protocols: Pelco D, Pelco P, Samsung, Visca, ONVIF, CoC
