SH-8100A5-8L(MM)
Input: Dynamic Hybrid
DVR Oriented: 8 Channel 4in1 HD Analog (BNC) + 8 Channel IP (Over Network)*
NVR Oriented: 0 Channel 4in1 HD Analog (BNC) + 16 Channel IP (Over Network)*
*Including all the HD Analog/IP variations available within the specified ranges.
Output: VGA: 1024x768/1280x1024/1920x1080
HDMI: 1024x768/1280x1024/1920x1080 / 3840x2160(4K)
CVBS (Can be used a spot)
HD Analog – 0-8 Channels
AHD/TVI: 8MP Lite
Max 12/15FPS Per Channel
Resolution: 3840x2160 (PAL/NTSC)
AHD/TVI: 5MP
Max 12FPS Per Channel
Resolution: 2560x1936 (PAL/NTSC)
AHD/TVI: 5MP Lite
Max 20FPS Per Channel
Resolution: 1280x1936 (PAL/NTSC)
AHD/TVI/CVI: 4MP
Max 12/15FPS Per Channel
4MP Resolution: 2560x1440 (PAL/NTSC)
AHD/TVI/CVI: 4MP Lite and lower
Max 12/15FPS Per Channel
4MP Resolution: 1280x1440 (PAL/NTSC)
(Supported Resolutions: 1080P, 720P)
CVBS: 960H
Max 25/30FPS Per Channel
Resolution: 960x575 (PAL) / 960x480 (NTSC)
IP – 8-16 Channels
IP: 8MP and lower
Max 25/30FPS Per Channel
Resolution: 3840x2160 (PAL/NTSC)
8 Channel Simultaneously (Local/Remote)
For IP Channels: Line Crossing, Sterile Area, Object Monitoring, Camera Tampering and Smart Search.
For HD Analog Channels: Line Crossing, Sterile Area and Smart Search.
Incoming: 32-64Mbps
Outgoing: 96Mbps
Input: 1 Channel (RCA) + IP Cameras inputs
Output: 1 Channel (RCA) + IP Cameras outputs
2 Way audio
1 x SATA (Up to 6TB)
2 x USB2.0
RJ-45: 100Mbps
Input: IP Cameras inputs only
Output: IP Cameras outputs only
