SH-8100A5N-5L(MM)
Input: 8CH Standard BNC + 4CH IP (Over Network)
Output: HDMI(1920x1080), VGA (1280x1024, 1024x768), CVBS(Spot)
IP: 5MP and lower: 30/25FPS Per Channel
AHD: 5MP Lite: Up to 10FPS Per Channel, 4MP Lite / 2MP: Up to 12/15FPS Per Channel, 2MP Lite / 1MP: Up to 25/30FPS Per Channel
TVI: 5MP Lite: Up to 10FPS Per Channel, 4MP Lite / 2MP: Up to 12/15FPS Per Channel, 2MP Lite / 1MP: Up to 25/30FPS Per Channel
CVI: 4MP Lite / 2MP: Up to 15/12FPS Per Channel, 2MP Lite / 1MP: Up to 25/30FPS Per Channel
CVBS: CVBS: 960H: Up to 30/25FPS Per Channel
8 Channel Simultaneously (Local)
4 Channel Simultaneously (Remote)
For AHD Cameras Line Crossing (No Direction Choice), Sterile Area, Smart Search
For IP Cameras Line Crossing (With Direction Choice), Sterile Area, Item Monitoring, Camera Tampering, Smart Search
Incoming: 32Mbps
Outgoing: 60Mbps
Input: 1 Channel (RCA) + IP Cameras inputs
Output: 1 Channel (RCA) + IP Cameras outputs
2 Way audio
1 x SATA (Up to 6TB)
2 x USB2.0
RJ-45: 100Mbps
Input: IP Cameras inputs
Output: IP Cameras outputs
1 x RS485
Protocol: Pelco D, Pelco P, Samsung, Visca, ONVIF, CoC
